9-12
9.2 Details of Function Codes
This section provides a detailed description of the function codes available for the FRENIC-Mini series
of inverters. In each code group, its function codes are arranged in an ascending order of the identifying
numbers for ease of access. Note that function codes closely related each other for the implementation of
an inverter's operation are detailed in the description of the function code having the youngest
identifying number. Those related function codes are indicated in the title bar as shown below.
F01 Frequency Command 1 Refer to C30.
9.2.1 F codes (Fundamental functions)
F00 Data Protection
Specifies whether function code data is to be protected from being accidentally changed by
keypad operation. If data protection is enabled (F00 = 1),
/ key operation to change data
is disabled so that no function code data, except F00 data, can be changed from the keypad.
Even if F00 = 1, function code data can still be changed using the communications
facility.
Data for F00 Function Setting procedure
0 Disable data protection.
1 Enable data protection.
Press
and
keys or
and
keys
simultaneously to change data from 1 to 0 or from 0
to 1, respectively. Press the
㩷key to save the
change.
F01 Frequency Command 1 Refer to C30.
Selects the devices to set the set frequency 1 for driving the motor.
Data for F01 Function
0
Enable
and keys on the built-in keypad. (Refer to Chapter 3
"OPERATION USING THE KEYPAD.")
1
Enable the voltage input to terminal [12] (0 to 10 VDC, maximum output
frequency obtained at 10 VDC).
2
Enable the current input to terminal [C1] (4 to 20 mA, maximum output
frequency obtained at 20 mA).
3
Enable the sum of voltage and current inputs to terminals [12] and [C1]. See the
two items listed above for the setting range and maximum frequencies.
Note: If the sum exceeds the maximum output frequency, the maximum output
frequency will apply.
4
Enable the built-in potentiometer (POT). (Maximum frequency obtained at full
scale of the POT)
There are other frequency setting means (such as the communications facility,
multistep frequency and etc.) with higher priority than that of F01. Refer to Chapte
r
4, Section 4.2 "Drive Frequency Command Generator" for more details.
