9.1 Function Code Tables
9-11
Chap. 9 FUNCTION CODES
* The table below lists the factory settings of "Fuji's standard torque boost," "Nominal rated current of Fuji
standard motor," and "Nominal rated capacity of Fuji standard motor" in the "Default setting" column of the
above tables.
Table 9.1 Fuji Standard Motor Parameters
Fuji's
standard
torque
boost (%)
Nominal rated current of
Fuji standard motor (A)
Nominal rated
capacity of Fuji
standard motor
(kW)
Function codes
F11, E34 and P03
Shipping destination
(version)
Power
supply
voltage
Applicable
motor
rating
(HP)
Inverter type
Function
code
F09
Asia EU Japan
Function code
P02
1/8 FRNF12C1

-2U 8.4 0.62 0.68 0.61 0.1
1/4 FRNF25C1

-2U 8.4 1.18 1.30 1.16 0.2
1/2 FRNF50C1

-2U 7.1 2.10 2.30 2.13 0.4
1 FRN001C1

-2U 6.8 3.29 3.60 3.36 0.75
2 FRN002C1

-2U
**
6.8 5.55 6.10 5.87 1.5
3 FRN003C1

-2U
**
6.8 8.39 9.20 8.80 2.2
Three-
phase
230 V
5 FRN005C1

-2U
**
5.5 13.67 15.00 14.38 3.7
1/2 FRNF50C1

-4U 7.1 1.09 1.15 1.07 0.4
1 FRN001C1

-4U 6.8 1.71 1.80 1.68 0.75
2 FRN002C1

-4U
**
6.8 3.04 3.05 2.94 1.5
3 FRN003C1

-4U
**
6.8 4.54 4.60 4.40 2.2
Three-
phase
460 V
5 FRN005C1

-4U
**
5.5 7.43 7.50 7.20 3.7
1/8 FRNF12C1

-7U 8.4 0.62 0.68 0.61 0.1
1/4 FRNF25C1

-7U 8.4 1.18 1.30 1.16 0.2
1/2 FRNF50C1

-7U 7.1 2.10 2.30 2.13 0.4
1 FRN001C1

-7U 6.8 3.29 3.60 3.36 0.75
2 FRN002C1

-7U 6.8 5.55 6.10 5.87 1.5
Single-
phase
230 V
3 FRN003C1

-7U 6.8 8.39 9.20 8.80 2.2
Note 1) A box () in the above table replaces S or E depending on the enclosure.
2) Asterisks (**) in the above table denote the following:
21: Braking resistor built-in type
(Available for 2 HP or above, three-phase 230 V and 460 V models)
None: Standard
