9-10
J codes: Application Functions
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
J01 PID Control
(Selection)
0: Disable
1: Process control use (Normal action)
2: Process control use (Inverse action)
—— N Y 0
J02 (Remote process
command)
0: Keypad
1: PID process command 1
(Data settings of E60, E61 and E62 are also
required.)
4: Communication
—— N Y 0
J03 P (Gain) 0.000 to 10.00 0.001
Times
Y Y 0.100
J04 I (Integration time) 0.0 to 3600.0 0.1 s Y Y 0.0
J05 D (Differentiation time) 0.00 to 600.00 0.01 s Y Y 0.00
J06 (Feedback filter) 0.0 to 900.0 0.1 s Y Y 0.5
9-64
y codes: Link Functions
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
y01
Link Functions for
RS-485
Communication
(Station address)
1 to 255 1 — N Y 1
y02 (Mode selection on no
response error)
0: Immediate trip and alarm E 8
1: Trip and alarm E 8 after running for the
period of the timer set by y03
2: Retry during the period of the timer set by
y03. If retry fails, trip and alarm
E 8
3: Continue to run
— — Y Y 0
y03 (Timer) 0.0 to 60.0 0.1 s Y Y 2.0
y04 (Baud rate) 0: 2400 bps
1: 4800 bps
2: 9600 bps
3: 19200 bps
— — Y Y 3
y05 (Data length) 0: 8 bits
1: 7 bits
— — Y Y 0
y06 (Parity check) 0: None
1: Even parity
2: Odd parity
— — Y Y 0
y07 (Stop bits) 0: 2 bits
1: 1 bit
— — Y Y 0
y08 (No response error
detection time)
0 (No detection), 1 to 60 1 s Y Y 0
y09 (Response interval) 0.00 to 1.00 0.01 s Y Y 0.01
y10 (Protocol selection) 0: Modbus RTU protocol
1: SX protocol (Loader protocol)
2: Fuji general-purpose inverter protocol
— — Y Y 0
9-70
y99 Link Function for
Supporting Data Input
Frequency command Run command
source source
0: by H30 by H30
1: via RS-485 by H30
communication
(option)
2: by H30 via RS-485
communication
(option)
3: via RS-485 via RS-485
communication communication
(option) (option)
— — Y N 0 9-73
