Fuji Electric frenic mini series - App.D Inverter Generating Loss

A-20
App.D Inverter Generating Loss
The table below lists the inverter generating loss.
Generating loss (W)
Power
supply
voltage
Applicable
motor
rating
(HP)
Inverter type
Low carrier
frequency
(2 kHz)
High carrier
frequency
(15 kHz)
1/8 FRNF12C1

-2U 20 23
1/4 FRNF25C1

-2U 27 32
1/2 FRNF50C1

-2U 40 50
1 FRN001C1

-2U 60 77
2 FRN002C1

-2U 91 110
3 FRN003C1

-2U 128 165
Three-
phase
230 V
5 FRN005C1

-2U 203 260
1/2 FRNF50C1

-4U 28 45
1 FRN001C1

-4U 41 64
2 FRN002C1

-4U 63 103
3 FRN003C1

-4U 89 149
Three-
phase
460 V
5 FRN005C1

-4U 135 235
1/8 FRNF12C1

-7U 21 24
1/4 FRNF25C1

-7U 29 34
1/2 FRNF50C1

-7U 41 51
1 FRN001C1

-7U 64 80
2 FRN002C1

-7U 101 129
Single-
phase
230 V
3 FRN003C1

-7U 143 180
Notes 1) A box (

) in the above table replaces S or E depending on enclosure.
