Fuji Electric frenic mini series - Crimp Terminals

6-6
6.2.2 Crimp terminals
Table 6.4 lists the recommended ring tongue crimp terminals that can be specified by the wires and screws
to be used for your inverter model.
Table 6.4 Crimp Terminal Size
Wire size [inch
2
(mm
2
)] Terminal screw size Ring tongue crimp terminal
M3.5 1.25 - 3.5
M4 1.25 - 4
M3.5 1.25 - 3.5
M4 1.25 - 4
M3.5 1.25 - 3.5
M4 1.25 - 4
M3.5 2 - 3.5
M4 2 - 4
0.005/0.009 (3.5/5.5)
M4 4 - 5.5
0.001 (0.5)
0.001 (0.75)
0.002 (1.25)
0.003 (2.0)

Refer to Chapter 8, Section 8.4.3 "Terminal arrangement diagram and screw specifications" to select
the correct terminal screw size.
