■ Continuous holding-down function for Program/Reset key
Holding down the key longer (approx. one second or longer) moves the cursor on the LED monitor.
In Running mode, the cursor moves along digits; in Programming mode, it moves not only along digits
but to the next function code.
■ Simultaneous keying
Simultaneous keying means depressing two keys at the same time (expressed by "+"). FRENIC-Mini
supports simultaneous keying as listed below.
(For example, the expression "
+ keys" stands for pressing the key while holding down the
key.)
Operation modes Simultaneous keying Used to:
Running mode Control entry to/exit from jogging operation.
+ keys
Programming mode
+ keys
Change special function code data.
(Refer to codes F00 and H03 in Chapter 9
"FUNCTION CODES.")
Alarm mode + keys Switch to Programming mode.
