Using IP Fax (SIP)
368
Using IP Fax (SIP)
10
Installation Procedures
This section describes the configuration procedures to use the IP Fax (SIP) feature on the
machine.
"Step 1 Enabling Port and Setting up TCP/IP" (P.368)
"Step 2 Configuring the SIP User Name" (P.369)
"Step 3 Configuring Fax Environment" (P.370)
"Step 4 Configuring the SIP Server" (P.371)
"Step 5 Registering the VoIP Gateway" (P.372)
Step 1 Enabling Port and Setting up TCP/IP
To use the IP Fax (SIP) feature on the machine, enable the port and set the IP addresses.
The following shows the configuration procedures on the machine.
z
You can configure the settings using CentreWare Internet Services. For information on how to use CentreWare Internet Services,
refer to "Configuring Machine Settings Using CentreWare Internet Services" (P.313).
1
Display the [Tools] screen.
1) Press the <Log In/Out> button.
2) Enter the system administrator's user ID with the numeric keypad or the keyboard
displayed on the screen, and select [Enter].
When a passcode is required, select [Next] and enter the system administrator's
passcode, and select [Enter].
z
The default user ID is "11111".
z
The default passcode is "x-admin".
3) Select [Tools] on the Services Home screen.
2
Enable the SIP port.
1) Select [Connectivity & Network Setup].
2) Select [Port Settings].
3) Select [SIP], and then select [Change Settings].
4) Select [Port Status], and then select [Change Settings].
5) Select [Enabled], and then select [Save].
6) Select [Close] repeatedly until the [Tools] screen is displayed.
3
Set an IP address and the other addresses.
Skip this step if an IP address is already set. If DHCP or BOOTP is available in your
environment, configure the method for obtaining the address. If an IP address cannot be
To Next Page
