HP-GL/2 Emulation
673
Appendix
16
Print control 151
(Hard clip)
Sets the size of hard clip area.
In HP-GL mode, the plottable area is determined in line with the paper size,
apart from the printable area. This area is called the "hard clip area", and
determines the maximum range of pen movement. Accordingly, images
cannot be drawn outside the boundary of the hard clip area.
[0] : Standard
[2] (Default) : Paper
z
For more information on hard clip area, refer to "Hard Clip Area" (P.675).
152
(Eject
command SP)
Sets the command that indicates the end of plotting. When the command
specified here is received, plotting is terminated and the paper is output.
[0] (Default): OFF
[1]: ON
The default value is [ON] for SPO, and [OFF] for the others.
z
If multiple commands are specified, when one of the commands is received, plotting is terminated
and the paper is output.
153
(Eject
command SPO)
154
(Eject
command NR)
155
(Eject
command FR)
156
(Eject
command PG)
157
(Eject
command AF)
158
(Eject
command AH)
159
(Scaling)
Sets whether the original size is enlarged or reduced so that the document
size fits the paper size.
[0]: OFF
[1] (Default) : ON
160
(Scalingmode)
Selects the document size for auto scaling: A series paper (A0, A1, A2, A3, A4,
and A6) or the active coordinate area which is determined accordance with
the setting selected in [Area Determination Mode].
[0] (Default) : Paper Size
[1] : Active Coordinate Area
z
[Active Coordinate Area] can be selected only when [Auto layout] is set to [ON].
When [OFF] is selected, [Scaling mode] becomes [Paper Size].
z
The setting of the scaling mode is valid when [Document size] is set to [Auto].
161
(Activeareadet
erminationcom
mand)
Sets the method to obtain the active coordinate area when auto scaling is
being used.
[0] (Default) : Auto
[1]: PS
[2]: IW
[3]: IP
[4]: Adapted
z
The setting of the active area determination command is valid when [Document
size] is set to [Auto].
To Next Page
