For Example:
If the following data is entered when the scaling mode is paper size, origin position is Auto,
paper margin is 10mm, and area determination mode is IP:
All pen width settings are 0.1 mm.
The following data does not contain a character size specification command and the A3
physical size of the area specified by IP/IW.
IN;
IP-8399,-5938, 8399, 5938;
IW-8399,-5938, 8399, 5938;
PU;
SP1;
:
:
SP0;
1) As the area determination mode is IP, the active coordinates area is specified as the area
-8399,-5938,8399,5938 by an IP command.
2) Because there are no font size specification commands and all pen widths are 0.1mm in
the above example, add the height/2 of the default font size for A3 size paper (75 plotter
units) to the active coordinates area obtained in step 1.
The active coordinates area obtained in step 2 is -8474,-6013,8474,6013.
3) The value set in paper margins (10 mm = 400 plotter units) is subtracted from the active
coordinates area obtained in step 2.
The active coordinates area obtained in step 3 is -8074,-5613,8074,5613.
4) As the active coordinates area obtained in step 3 exceeds the A4 size and is A3 size, the
document size is determined to be A3.
In addition, when the paper margin setting is 0 mm and the active coordinates area is
8474,-6013,8474,6013, and this exceeds A3, but is A2 or smaller, the document size is
determined to be A2.
If the operation panel settings are as follows, the paper size is determined as below.
Document size: Auto
Paper Tray: Auto
The method for determining the paper size differs according to the paper size and scaling
mode settings on the operation panel.
îš„ If the Paper Size Setting is A Sizes
The paper sizes among the three sizes (A3, A4, and A5) that are actually loaded in the trays
become the possible paper size.
If A series paper (A3, A4, A5) is not loaded in the trays, all three sizes, A3, A4, and A5
become possible sizes; a message is displayed on the touch screen prompting the user to
load A series paper.
îš„ If the Paper Size Setting is Auto
The paper sizes among the five sizes (A3, B4, A4, B5, and A5) that are actually loaded in the
trays become the possible paper size.
If A3, B4, A4, B5, or A5 paper is not loaded in the trays, all five sizes become possible sizes; a
message is displayed on the touch screen prompting the user to load paper.
