2 Product Overview
46
Product Overview
2
Note • The Finisher-B1 is optional. In this guide, the Finisher-A1 and Finisher-B1 are referred to as
the "finisher".
• The power cord connected to the Finisher-B1 is a connecting cord dedicated to the machine.
Do not connect this cord to any other devices than the machine.
12 Hole-punch waste
container
Collects scraps from the puncher.
13 US 2/3 Hole Punch Kit (US
standard) (optional)
2/4 Hole Punch Kit
(optional)
Hole-punches outputs.
Note • The distance between the two holes made with
the US 2/3 Hole Punch Kit (US standard) is 70
mm, which is different from the 80 mm distance
made with the 2/4 Hole Punch Kit.
14 Center tray (Top transport
cover)
Copies and prints are delivered here when they are
unable to be delivered to the output tray or the finisher
tray.
Pull the cover upward when clearing paper jams.
Note • Remove outputs delivered to the center tray
constantly.
No. Component Function
To Next Page
