About the display if a position link has been set
Position Copy
● The reference image is fixed
at the link source.
● The slice center position and
angle are fixed at the link source.
(The slice lines cannot be moved.)
(The lines are displayed in blue.)
Position Link
● Copy parameters can be set.
● This function is effective when
the number of slices is changed
at the copy source.
Select the link source.
In the Acquisitions area, select the imaging
operation whose slice line position you want to
use.
You do not need to select anything when
releasing the link.
Click .
● The icon is displayed before the task name in
Acquisition Plan.
Chapter 6 Imaging
- 6.7 Position Links -
