Ports and controls
Ports and controls
This chapte r presents the individual hardware components of your device. It gives
you an overview of the de vice ’s indicators and connections. Familiarise yourself with
these components before you start to work with the device.
Front
3
2
1
4
5
6
7
8
9
1 = WebCam
2 = Battery charging indicator
3 = Ambient light sensor
4 = Volume buttons
5 = Micro USB port
6 = Reset button (beneath cover)
7 = Memory card slot (Micro SD,
beneath c over)
8 = SIM card slot (beneath cover)
9 = Port for mains adapter, cradle and
USB/HDMI adapter
Fujitsu Technology Solutions 9
