Fujitsu STYLISTIC Q704 User Manual

Appendix
Recovering Yo ur Recovery Image Using Recovery and Utility
(for new hard drive or non-boot
able hard drive)
If you have installed a new hard drive or your hard d rive is not bootable, perform the following steps.
Note: You will need the Bootable disk and Recovery Image disk set for this recovery.
1. Power on your system. When the Fujitsu logo appea rs o n the screen, press the
Enter
key.
2. Insert the bootable disk in your DVD drive, then click OK.
3. Highlight the CD/D VD option from the Boot Menu and press
Enter
.
4. Select CD/DVD boot mode: Select UEFI Mode, if applicable an d press
Enter
.
While the files are being loaded from the disk, the Fujitsu logo screen app ears
followed by a progress bar at the bottom o f the screen.
5. Choose your language, if necessary.
6. Three tool options appear: Diagnostics, Recovery and Utility. S elect Recovery.
• For Windows 8.1: Select Restore full hard drive
• For Windows 7: Select Restoring the Factory Image (full hard d rive recovery)
7. Click Next to confirm full hard drive restoration. All data on HDD will be deleted.
8. Agree to EULA by selecting Agree option an d clicking Next.
9. Click Next on the Recovery Disk Check screen to verify that the bo otable
disk has been inserted into the optical d rive.
10. The Checking for Recovery Disk screen appears followed by the prompt to insert the
first disk. Click OK to continue. Repeat this step for all disks. After all recovery disks
have been checked an d the check has been completed, click Next.
11. Follow the prompt to reinsert the first r ecovery disk and click Next.
12. Click OK when you receive the fin al warning informing you that all data on drive
C will be lost. This starts the recovery process.
13. Follow the prompts to inse rt the next recovery disks and click OK.
14. After the copying of the image to the H DD completes the restore process is
complete, c lick Finish to restart the system. The computer will restart automatically
and then go t hrough the firstbootprocess.
15. Follow the steps listed in “Auto Installation support for essential access
software from backup location” section.
16. Download FSDM (Fujitsu Software Download Manager) from sup port site and download
all the software applicable to the model and OS using FSDM.
17. Follow the steps listed in “Auto Installation support for essential access
software downloaded from support website.
Fujitsu 105

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	11.9 mm
Weight	998 g
