Technical data
WLAN specifications
Type of ne twork For Intel® Wilkins Peak2: Intel® Dual Band
Wireless-N 7260
Transfer rate (Automatic switching) IEEE802.11 a and g: 54
Mbps max. data rate; IEEE802.11n: 300 Mbps
max. data rate
Active frequency • 802.11n: 2.4 GHz or 5 GHz
• 802.11b/g: 2400~2473 MHz
• 802.11a: 4900~5850 MHz
Typical operating dis
tances
• 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft.
(91m)@6Mbps
• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft.
(91m)@1Mbps
• 802.11g: 100 ft. (30 m ) @ 54 Mbps; 300 ft.
(91m)@1Mbps
• 802.11n: Estimated double the operating
distance of 802.11g and 802.11a in their
respective frequencies
Number of channels
• 802.11a: 8 independent channels
• 802.11b/g: 11 channels, 3 non-overlapping
channels
• 802.11n: Channel bonding takes two of
the non-overlapping 20MHz channels and
combines it into o ne 40MHz channel. It is
actually 12 non-overlapping c hannels with
channel bonding and 24 without. Also, it is
1 non-overlapping channel in 2.4GHz when
channel bo nding is used
Security Encryption Types: WEP, TKIP, AES, WPA 1.0
and WPA 2.0 compliant
Encryption Key lengths Supported: 64 bits and
128 bits
Maximum recommended number of computers
to be connected over w ireless LAN (during ad
hoc connection)
10 units or less
Rechargeable battery
3-cel
l lithium polymer battery 4250 mAh
Rate
d voltage
10.8
V
Rat
ed capacity
46 W
h
84 Fujitsu
