First-time setup of your device

Choose a location

ChoosealocationSetupACadapter

Choose a suitable location for the de vice before setting it up. In doing

so, please follow these instructions:

• Never place the device or the AC adapter on a heat-sensitive surface.

The surface could be damaged as a result.

• Never place the device on a soft surface (e.g. carpeting, upholstered furniture,

bed). This can result in damage caused by overheating.

• The underside of the device heats up during normal op eration. Prolonged

contact with skin can become unpleasant or even result in bu rns.

• Place the device on a stable, ﬂat, non-slippery surface. Please note that the

rubber feet of the device may mark certain types of delicate surfaces.

• Keep other objects a t least 100 mm / 4 inches away from the device

and its AC adapter to ensure adequate ventilation.

• Do not expose the device to extreme environmental conditions. Protect

the device against dust, humidity and heat.

Connecting the AC adapter

MakingreadytouseACadapter

Observe the safet

y notes in the enclosed "Safety/Regulations" manual.

ThesuppliedACc

able conforms to the requirements of the country in which

you purchased yo

ur device. Ma ke sure tha t the AC cable is approved fo r

use in the count

ry in which you intend to use it.

► Open the cover o f the DC jack

socket (DC IN).

► Connect the AC cable (1) to the AC adapter.

► Plug the AC cable (2) into a po wer outlet.

► Connect the AC adapter cable (3) to the

DC jack socket (DC IN) of the device.

18 Fujitsu

Questions and Answers:

Need help?

Do you have a question about the Fujitsu STYLISTIC Q704 and is the answer not in the manual?

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00
