Technical data
Technical data
Tablet PC
General
Processor
Core i5 or core i7 (dependent on conguration)
Main memory (SO DIMM) Core i5: 4 GB
Corei7:8GB
Electrical data
Safety regulations complied with CE
Protection class II
Maximum power consum
ption (when the Tablet
PC is switched on, co
nnected to the keyboa rd
cover and the batte
ry is charged):
65 W
Touchscreen
Size 12.5" Full HD Wide View IPS
Screen resolution 1920 x 1080 / 16 million colors
Pixel cla ss II
Brightness control 12 levels
Technology Wide-View High-Bright Display with LED
background lighting
Digitizer and glass panel
Dual digit
izer with Glare touch scre en
Cameras
Front: HD
camera
Back: 8 megapixels, autofocus, mobile light
Graphics card
Chip Intel® HD Graphics 4400
Maximum resolution of external display:
1920 x 1080
Dimensions
Width x Depth x Height
Standard Shell tablet only: 12.19 x 7.85 x 0.47
inches (309.6 x 199.3 x 11.9 mm)
Standard Shell ta blet w/keyboard cover: 12.19 x
7.85 x 0. 79 inches (309.6 x 199.3 x 20 mm)
Standard Shell tablet w/keyboard docking
station: 12.19 x 7.85 x 1.22 inches (309.6 x
199.3 x 31.1 mm)
Smart Ca rd Shell tablet only: 12.19 x 7.85 x 0.74
inches (309.6 x 199.3 x 18.8 mm)
Smart Card She ll tablet w/keyboard cover: 12.19
x 7.85 x 1.09 inches (309.6 x 199.3 x 27.8 mm)
Smart Card Shell tablet w/keyboard docking
station: 12.19 x 7.85 x 1.31 inches (309.6 x
199.3 x 33.3 mm)
82 Fujitsu

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu STYLISTIC Q704 and is the answer not in the manual?

Fujitsu STYLISTIC Q704 Specifications

General IconGeneral
LED backlightYes
Pixel density176 ppi
Display diagonal12.5 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness352 cd/m²
Native aspect ratio16:9
Display number of colors16.78 million colors
Bus typeDMI2
SteppingD0
Tjunction100 °C
Processor codeSR1EA
Processor cache4 MB
Processor cores2
Processor modeli7-4600U
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4600 Mobile series
Processor threads4
Processor codenameHaswell
Processor frequency2.1 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size40 x 24 x 1.5 mm
Processor front side bus- MHz
Processor boost frequency3.3 GHz
Processor operating modes64-bit
PCI Express configurations4x1, 2x4
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)15 W
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeLPDDR3-SDRAM
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB
Internal storage capacity256 GB
Graphics cardHD Graphics 4400
Audio systemRealtek ALC283
Flash typeLED
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Wi-Fi data rate (max)300 Mbit/s
Microphone inNo
Headphone connectivity3.5 mm
USB 2.0 ports quantity0
Micro-USB 2.0 ports quantity1
Device typeTablet PC
Form factorConvertible (Detachable)
Product colorBlack
Sustainability certificatesRoHS, ENERGY STAR
CertificationCB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location-
Password protection typeBIOS, Supervisor, User
PlatformWindows
Trial softwareMcAfee Internet Security
Bundled softwareAdobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installedWindows 8.1 Pro
Battery voltage10.8 V
Battery capacity4250 mAh
Battery life (max)10 h
Battery recharge time2.3 h
Number of battery cells3
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.42 A
AC adapter output voltage19 V
Storage temperature (T-T)-15 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 85 %
Operating relative humidity (H-H)20 - 85 %
Processor ARK ID76616
Processor socketBGA 1168
Intel TSX-NI version0.00
Intel ME Firmware Version9.5
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth199.3 mm
Width309.6 mm
Height11.9 mm
Weight998 g
