Fujitsu STYLISTIC Q704 User Manual

Appendix
Creating a Backup of Essential Access Software
When you purchased your new system, a “Fujitsu Software Extractor” shortcut was loaded to
“C:\Fujitsu\Drivers\AutoInstaller\”. This shortcut allows you to save the software driver packages
along with the extracted Auto Installer software package to a selected location. It is recommended
that you save these packages to writable m edia or an external drive. This ensures that in the
event of system failure you will be able to re-install the essential acce ss software.
1. Open the C:\Fujitsu\Drivers\AutoInstaller\ folder
2. Run “Fujitsu Software Extractor” as an Administrator
a. Right-click on Fujitsu Software Extractor.
b. Select the “R un as A dminist rator” option from the menu that is displayed.
3. The default save location is C:\Fujitsu\ AutoInstaller\ Drivers\. You can change the location
by clicking on the Browse button and selecting your preferred location.
Note: It is recommended that you change the default location and save the
software packages to the external writable media or drive.
4. Click on the Save Packages bu tton.
5. Fujitsu Software Extractor copies the zipped software packages and Readme files,
and extracts the Auto Installer folder to the selected l oca tion.
Note: The extracted A uto Installer will later be used to install the soft ware
automatically on the system in the event of generic image restoration when
the software is not pre-installed in the image.
RECOVERYOURSY
STEM WHEN THE HARD
DRIVE IS S TILL ACCESSIBLE
Using the Recovery and Utility Tools
The Recovery and Utility tools consist of a variety of tools that will help you recover your
recovery image and system images, and delete the data from your hard disk.
Methods for accessing the utilities
Recovery and Utility Tools are preinstalled in a hidden partition by the factory, or
they can be accessed by using the bootable disk.
Note: The Recovery and Utility tools may be deleted from your hard disk
drive if you modify the partitions. If that occurs, you will not be able to
use the hidde n partition for booting to Recovery and Utility Tools, but you
will still be able to boot from the Bootable Disk.
Fujitsu 101

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	11.9 mm
Weight	998 g
