Working with the Tablet PC
Delete functions are not supported by the stylus.
Action Mouse
Stylus
Selecting menu
items
Click with the left mouse button. Tap on the menu entry with the tip of
the stylus.
Starting programs Double-click with the left mouse
button.
Tap o n the program symbol twice in
rapid succession using the stylus tip.
Moving an object
or window
Drag with the left mouse bu
tton
pressed.
Place the stylus tip directly on the
object or w indo w. Keep the stylus tip
held against the screen. Drag the
desired object o r window.
Opening a context
menu
Click with the right mou
se button.
Tap on the desired element with the
stylus and keep the stylus pressed
against the screen.
Moving the cursor
-
Place the tip of the st
ylus directly on
the screen.
Stylus location
On delivery, the stylus is located in the stylus
garage:
1
Adjusting the stylus
Operating system Menu
Windows 7 Under HardwareandSound-PenandInputDevices,youcanmakevarious
settings for the stylus in the control panel (assignment an d function of
the stylus button).
Windows 8.1 Under Windows 8.1 Desktop - Control Panel - Hardware and Sound - Pen and
Input Devices you can make various settings for the stylus (assignment
and function of the stylus button).
32 Fujitsu

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	11.9 mm
Weight	998 g
