Fujitsu STYLISTIC Q704 User Manual

Security functions
Changing the supervisor HDD password or user HDD password
You can only change the supervisor HD D password when you have logged into the
BIOS Setu p Utility with the s upervisor HDD password.
PasswordSupervisorHDDpasswordUserHDDpassword
► Start the BIOS Se tup Utility and go to the Security menu.
► When changing the password, proceed exactly as when assigning a password.
Removing passwords
To remove a passw ord (without setting a new password) perform the following steps:
PasswordSupervisorpasswordUserpassword
► Start the BIOS Se tup Utility and go to the Security menu.
► Highlight the Set Supervisor P assword or Set User Password field and press the Enter key.

You will be requested to enter the current password by the Enter Current Password promp t.
Enter New Password will appea r and you will be requeste d to enter a new password.
► Press the Enter key twice at this r equest.
► In the Exit menu, select the option Save Changes & Exit.
► Select Yes and press the Enter k ey.

The Tablet PC is rebooted and the password is remove d.
Removing the supervisor password simultaneously deactiva tes the user password.
Password protection for booting the operating system
You can also pre
vent booting of the operating syste m with the supervisor
HDD password yo
u have set in the BIOS Setup U tility (see section "
Assigning
the superviso
r and user passwords", Page 63).
Operating system
Activating system protection
► Start the BIOS Se tup Utility and go to the Security menu.
Operatingsystem
► Select the Password on Boot option and press the Enter k ey.
► Select the option you require (Disabled, First Boot or Every Boot ) and press the e nter key
► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. You will be prompted to enter your password (the supervisor password).
Deactivating system protection
► Start the BIOS Se tup Utility and go to the Security menu.
Operatingsystem
► Select the Password on Boot option and press the Enter k ey.
► Select the Disabled option and press the Enter k ey.

If you d o not want to change any other settings, you can exit BIOS Setup Utility.
► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. The system is no longer password pro tect ed.
64 Fujitsu

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	11.9 mm
Weight	998 g
