Fujitsu STYLISTIC Q704 User Manual

Contents
SIM card ............................................................................... 39
Inserting aSIM card ................................................................. 39
Removing a SIM card ............................................................... 40
Wireless LAN /Bluetooth/4G/NF C wireless components . . . .................................. 40
Switching the wireless com ponents on and off ......................................... 40
Furtherinformation on WLANand Bluetooth ........................................... 41
Accessvia WirelessWAN ............................................................ 41
NFC ............................................................................... 41
Ethernet and LAN (only with performance do cking cradle or keyboard docking station) . . . . .... 41
GPS ................................................................................... 42
Accessories for your Tablet PC (optional) . ............................................. 43
Your performance docking cradle (optional) . . ............................................. 44
Cradle components . . ................................................................ 44
Setting up thecradle ................................................................ 45
Connecting the Tablet PC to the cradle . . ............................................. 45
Disconnecting the Tablet PC from the c radle . ......................................... 47
Keyboard cover (optional) . . . ............................................................ 48
Keyboard cove r components . ........................................................ 48
Connecting the Tablet PC to the keyboard cover . . . . . .................................. 49
Separating the Tablet PC from the keyboard cover . . .................................. 50
Keyboard docking station (o ptional) . . . . . . ................................................. 51
Ports on the keyboard docking station . . . ............................................. 51
Connecting the Tablet PC to the keyboard docking station .............................. 53
Separating the Tablet PC from the keyboard docking station . . .......................... 54
VESA mounting attachment (optional) . . . ................................................. 55
Hand strap (optional) . . . . ................................................................ 56
Shoulder strap (optional) ................................................................ 57
Folio case (optional) . . . . . ................................................................ 58
MicroUSB adapters ..................................................................... 59
Security functions ..................................................................... 61
Configuring the fi ngerprint sensor ........................................................ 62
Configuringpasswordprotectionin BIOSSetupUtility ...................................... 63
Protecting BIOS Setup Utility (supervi sor HDD password and user HDD passw ord) . . . .... 63
Password protection for booting the operating system .................................. 64
Passwordprotectionfor the harddisk ................................................. 65
Smart Card reader (optional) . ............................................................ 66
Inserting theSmartCard ............................................................. 66
Trusted Platform Module - TPM (device dependent) . . . . . . .................................. 67
Enabling TPM ....................................................................... 67
Disabling TPM ...................................................................... 67
Connecting externaldevices ........................................................... 68
Connecting an external monitor . . ........................................................ 69
HDMI port(onlyperformancedocking cradle andkeyboarddocking station) .............. 69
External mo nitor port (VGA) (only perfo rma nce docking cradle and keyboard docking
station) ............................................................................. 69
Connecting USB devices ................................................................ 70
How toremove USBdevicescorrectly ................................................ 70
Headphones port ....................................................................... 71
Settings in BIO S Setup Utility . . ........................................................ 72
Starting theBIOS Setup Utility ........................................................... 72
4 Fujitsu

Fujitsu STYLISTIC Q704 Specifications

General

LED backlight	Yes
Pixel density	176 ppi
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	352 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor code	SR1EA
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	256 GB
Graphics card	HD Graphics 4400
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	300 Mbit/s
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Convertible (Detachable)
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Certification	CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL
Position location	-
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security
Bundled software	Adobe Reader Fujitsu LIFEBOOK Application Panel Fujitsu Display Manager ShockSensor Utility Power Saving Utility Fujitsu Plugfree Network EasyGuide online user documentation
Operating system installed	Windows 8.1 Pro
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	10 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	76616
Processor socket	BGA 1168
Intel TSX-NI version	0.00
Intel ME Firmware Version	9.5
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	11.9 mm
Weight	998 g
