FHE-250 MANUAL 09 2014 ISSUE 2
Page 4
FIG. 2 GENERAL ARRANGEMENT WITH PANELS REMOVED
Venturi
Fan
Electrical Plate
Heat Exchanger
Return Pipe
Flow Pipe
Gas
Valve
Condensate
Pipe
Automatic
Air Vent
