FULTON FHE-250 - History Mode

FHE-250 MANUAL 09 2014 ISSUE 2
Page 40
3
3.14.10
HISTORY MODE
LCD -when selecting the burner:
seg1 to seg2 Displayed “bu”
seg4 Burner number (from 0 to E)
LCD -when selecting the history index:
seg1 to seg2 Displayed “Hi”
seg3 to seg4 Index number (starting from 0)
LCD -when showing the error code:
seg2 to seg3 Numeric value (refreshed every 3 sec.)
Button Press: Function:
C for 3 sec. Exit history mode
Briey B Conrm selection and shift to the next page (burner -> index -> code)
D Decrement index number, skip to index selection screen
E Increment index number, skip to index selection screen
F Decrement burner number, skip to burner selection screen
G Increment burner number, skip to burner selection screen
Note: When the mode is invoked, indicates burner selection. User interface is switched to Index selection after 3
seconds or on demand. Index starts from number 0. After 1 second index is replaced by related error code.
A
B
C
E
D
G
F
C for 3 sec.
