FULTON FHE-250 - Page 5

FHE-250 MANUAL 09 2014 ISSUE 2
TITLE FIG. NO.
General Arrangement 1
General Arrangement with Panels Removed 2
Typical Gas Train 3
Flue Gas Conditions 4
Boiler Hydraulic Resistance 5
Boiler Communication Cables 6
Electrical Terminals 3-13 Disconnected 7
Jumper 8
Inserted Jumper Between Terminals 19 and 20 9
LCD Glass Layout 10
Push-button Layout 11
Boiler Dimensions 12
Name Plates 13
LIST OF ILLUSTRATIONS
