TROUBLESHOOTING - 6
245/254
Building Technologies Division Basic documentation LMV26... CC1P7547en
30 Error code list 20.04.2016
Error code Diagnostic code Meaning for the LMV26... system Remedy
SQM33.7) between 2 curve points in modulating mode.
2. Modulating operating ramp 64 seconds
The slope of the curve may be a maximum position change of 62° (30° for SQM33.6 and 18° for
SQM33.7) between 2 curve points in modulating mode.
Bit 4
Valency
16
Sectional deviation in comparison with last referencing
Actuator was overloaded or mechanically twisted.
1. Check the setting of the actuator type (parameter 613.1)
2. Check to see if the actuator is blocked somewhere along its working range.
3. Check to see if the torque is sufficient for the application.
90 # Internal error basic unit
91 # Internal error basic unit
93 # Error flame signal acquisition
3 Short-circuit of sensor
Short-circuit at QRB...
1. Check wiring.
2. Flame detector possibly fault.
95 # Error relay supervision
3 Ignition transformer
4 Fuel valve 1
5 Fuel valve 2
6 Fuel valve 3
External power supply NO contact
Check wiring
96 # Error relay supervision
3 Ignition transformer
4 Fuel valve 1
5 Fuel valve 2
6 Fuel valve 3
Relay contacts have welded
Test the contacts:
1. Unit connected to power: Fan output must be dead.
2. Disconnect power: Disconnect fan. No resistive connection between fan output and neutral
conductor allowed.
If one of the 2 tests fails, release the unit since contact have definitively welded and safety can
no longer be ensured.
97 # Error relay supervision
0
Safety relay contacts have welded or external power supply fed to
safety relay
Test the contacts:
1. Unit connected to power: Fan output must be dead.
2. Disconnect power: Disconnect fan. No resistive connection between fan output and neutral
conductor allowed.
If one of the 2 tests fails, release the unit since contacts have definitively welded and safety can
no longer be ensured.
98 # Error relay supervision
2 Safety valve
3 Ignition transformer
4 Fuel valve 1
5 Fuel valve 2
6 Fuel valve 3
Relay does not pull in
Make a reset; if error occurs repeatedly, replace the unit
