Page 79
TROUBLESHOOTING - 6
246/254 Building Technologies Division Basic documentation LMV26... CC1P7547en 30 Error code list 20.04.2016 Error code Diagnostic code Meaning for the LMV26... system Remedy 99 # Internal error relay control Make a reset; if error occurs repeatedly, replace the unit
3 Internal error relay control
Make a reset. If error occurs repeatedly, replace the unit Software version V03.10: If error C:99 D:3 occurs during standardization of the VSD, deactivate temporarily function
Alarm in case of start prevention (parameter 210 = 0, when using a release
contact) or
interrupt the controller-ON signal
100 # Internal error relay control Make a reset; if error occurs repeatedly, replace the unit 105 # Internal error contact sampling
0 Pressure switch-min 1 Pressure switch-max / POC 2 Fuel selection Fuel 0 / Reset 3 Air pressure 4 Load controller open 5 Load controller on / off 6 Load controller close 7 Safety loop / Burner flange 8 Safety valve 9 Ignition transformer 10 Fuel valve 1 11 Fuel valve 2 12 Fuel valve 3 13 Fuel selection Fuel 1 / Reset
Stuck-At failure
Can be caused by capacitive loads or supply of DC voltage to the mains voltage inputs. The diagnostic code indicates the input where the problem occurred
106 # Internal error contact request Make a reset; if error occurs repeatedly, replace the unit 107 # Internal error contact request Make a reset; if error occurs repeatedly, replace the unit 108 # Internal error contact request Make a reset; if error occurs repeatedly, replace the unit 110 # Internal error voltage monitor test Make a reset; if error occurs repeatedly, replace the unit 111 # Power failure
Mains voltage to low Exchange ratio diagnostics code
 voltage value (230 V: 1.683)
112
0 Mains voltage recovery
Error code for triggering a reset on power restoration (no error)
113 # Internal error mains voltage supervision Make a reset; if error occurs repeatedly, replace the unit 115 # Internal error system counter 116
0 Designed life time exceeded (250´000 startups)
Warning threshold has been reached. The unit should be replaced
117
0
Life time exceeded Operation no longer allowed
Switch-off threshold has been reached
120
0 Interrupt limitation fuel meter input
Too many disturbance pulses at the fuel meters input
