Furuno FS-5000 User Manual

Appendix
AP2-6
(8) Ripple Voltage 100 mVp-p or less
(9) Insulation Resistance 500VDC 50M ohms or more between AC
input and chassis
2. Environmental Condition
(1) Ambient Temperature -20
O
C to +55
O
C
(2) Relative Humidity 95 % max.
BC-6158 : Battery charger
1. Applicable Battery 200AH Normal Ship Battery
2. Power Supply 100/110/200/220VAC, single phase,
50/60Hz, l.5kVA max.
3. Output for battery 28VDC, 30A (full charging)
4. Charge/discharge Meter Provided on the radio console panel
5. Control Panel Provided on the radio console panel
6. Environmental Conditions
Ambient Temperature -20
O
C to +55
O
C
Relative Humidity 95% max. at +40
O
C

Furuno FS-5000 Specifications

General

Output Power	150 W (PEP)
Tuning	Synthesized
Type	MF/HF Radio Transceiver
Frequency Range (Transmit)	1.6 to 27.5 MHz
Frequency Range (Receive)	100 kHz to 30 MHz
Modulation	J3E (SSB), H3E (AM)
Emission Modes	J3E, H3E, F1B, A1A
Power Supply	24V DC
DSC	Yes
