FELCOM 81
H2-2
2. System settings list
Settings item
Unit Function
Setting Note
IB-181 Limit switch
Antenna hatch
direction
Depend on the
Antenna installation.
IB-281
RF CONV
board:R135
Tx RF signal
output level.
Depend on the
Antenna cable
length.
Cable length
8DFB-CV
10 to40m:Marked position (default)
40 to 50m:CW MAX.
12DSFA-CA
50 to 100m:CW MAX.
FC622SL1WG
Pb: Pushbutton [STO] [#] [*] [STO]
TEL
FC755D1
Dialing format
DIP SW #1 ON
Dialing format PB
Modem speed:
9600
(B FAX)
9600bps
Modem
speed:2400
2400bps
Monitor ON or OFF
Language Japanese or English
FAX
*PFX-50
ECM OFF
Refer to section
“3.4 FAX settings:PFX-50”.
AAB IMN 4Char. X
[F4][3][8]
Reentering AAB:[Alt]+[Ctrl] type
“ANSWER”
Entering
OID/DID
Assigned OID/DID
CPU2 DIP SW S2#2 ON
or
Displaying the commissioning menu
by commands
**Job number & Pass word**
- Job number: FURUNOSERVICE
- Password : FELCOM81
DMG message:
Ship’s name
Ship’s name :4Char.
[F4][6][3]
1:Abbr.ship’s Name
2: Maritime
3:Undesignated
Termin
al Unit
IB-581
Network Setup Select sea area [F4][6][4]
*PFX-50
All Memory Clear
When the FAX is turned off for a long period, it dose not function properly, became of
abnormality of the FAX’s memory (RAM) contents.
1. Turn the power off.
2. While pressing and holding down [1] [3] and [*] keys together, turn the power on.
3.
Preset various settings.
