A.6 Sensor List
Sensor
Description
Component
Inlet Temp
Air inlet temperature
Left mounting ear
Outlet Temp
Air outlet temperature
Mainboard
PCH Temp
PCH bridge temperature
Mainboard
CPUN Core Rem
CPU core temperature
CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN DTS
CPU DTS value
CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN Margin
CPU Margin
CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN VDDQ Temp
CPU VDDQ temperature
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN VRD Temp
CPU VRD temperature
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN MEM Temp
CPU DIMM temperature
DIMMs of CPU N
N indicates the CPU
number. The value
ranges from 1 to 2.
SYS 3.3V
Mainboard 3.3 V voltage
Mainboard
SYS 5V
Mainboard 5.0 V voltage
Mainboard
SYS 12V_1
Mainboard 12.0 V voltage
Mainboard
SYS 12V_2
Mainboard 12.0 V voltage
Mainboard
CPUN VCore
1.8 V CPU voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN DDR VDDQ
1.2 V DIMM voltage
Mainboard
N indicates the CPU
number. The value
