Fusion FusionServer 2288H V5 User Manual

FusionServer 2288H V5 Server
Technical White Paper
A Appendix
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
112
Sensor
Description
Component
ranges from 1 to 2.
CPUN DDR VDDQ2
1.2 V DIMM voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN VSA
CPU VSA voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN VCCIO
CPU VCCIO voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN VMCP
CPU VMCP voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
PCH VPVNN
PCH VPVNN voltage
Mainboard
PCH PRIM 1V05
PCH PRIM voltage
Mainboard
CPUN VCCP
CPU VCCP voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN DDR VPP1
VPP_ABC voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN DDR VPP2
VPP_DEF voltage
Mainboard
N indicates the CPU
number. The value
ranges from 1 to 2.
FANN Speed
Fan speed sensor
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
Power
Server input power
PSU
PSN VIN
PSUN input voltage
PSUN
N indicates the PSU
number. The value is 1 or
2.
Disks Temp
Drive maximum
Drive
