FusionServer 2288H V5 Server
Technical White Paper
A Appendix
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
113
Sensor
Description
Component
temperature
PowerN
PSU input power
PSUN
N indicates the PSU
number. The value is 1 or
2.
PCH Status
PCH chip fault diagnosis
health status
Mainboard
CPUN QPI Link
CPU QPI link fault
diagnosis health status
Mainboard or CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN Prochot
CPU Prochot
CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN Status
CPU status
CPUN
N indicates the CPU
number. The value
ranges from 1 to 2.
CPUN Memory
CPU memory status
DIMMs of CPU N
N indicates the CPU
number. The value
ranges from 1 to 2.
FANN Status
Fan status
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
DIMMN
DIMM status
DIMMN
N indicates the DIMM slot
number.
RTC Battery
RTC battery status. An
alarm is generated when
the voltage is lower than 1
V.
RTC battery
PCIE Status
PCIe status
PCIe card
Power Button
Power button pressed
state
Mainboard and power
button
Watchdog2
Watchdog timer
Mainboard
Mngmnt Health
Management subsystem
health status
Management module
UID Button
UID button status
Mainboard
