Fusion FusionServer 2288H V5 User Manual

FusionServer 2288H V5 Server
Technical White Paper
A Appendix
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
114
Sensor
Description
Component
PwrOk Sig. Drop
Voltage dip status
Mainboard
PwrOn TimeOut
Power-on timeout
Mainboard
PwrCap Status
Power capping status
Mainboard
HDD Backplane
Entity presence
Drive backplane
HDD BP Status
Drive backplane health
status
Drive backplane
RiserN Card
Entity presence
Riser card N
N indicates the riser card
slot number. The value
ranges from 1 to 3.
SAS Cable
Entity presence
SAS High-speed cable
FANN R Presence
Fan presence
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
RAID Presence
RAID controller card
presence
RAID controller card
LCD Status
LCD health status
LCD
LCD Presence
LCD presence
LCD
PS Redundancy
Redundancy failure due
to PSU removal
PSU
NIC# Status
NIC fault diagnosis health
status
LOM port
Port# Link Down
Network port link state
LOM port
PSN Status
PSU status
PSUN
N indicates the PSU
number. The value is 1 or
2.
PSN Fan Status
PSU fan status
PSUN
N indicates the PSU
number. The value is 1 or
2.
PSN Temp Status
PSU presence
PSUN
N indicates the PSU
number. The value is 1 or
2.
DISKN
Drive status
Drive N
N indicates the drive slot
number. The value
