Sensor
Description
Component
ranges from 0 to 24 or
from 36 to 47.
LOM P1 Link Down
LOM
LOM
LOM P2 Link Down
LOM
LOM
LOM P3 Link Down
LOM
LOM
LOM P4 Link Down
LOM
LOM
PCIe RAID$ Temp
PCIe RAID controller card
temperature
PCIe RAID controller card
M2 Temp(PCIe$)
Maximum temperature of
all M.2 drives of the RAID
controller card
PCIe RAID controller card
RAID Temp
RAID controller card
temperature
RAID controller card
RAID Status
RAID controller card
health status
RAID controller card
RAID PCIE ERR
RAID controller card fault
diagnosis health status
RAID controller card
IB$ TEMP
IB adapter temperature
IB card
PCIe$ OP Temp
PCIe card optical module
temperature
PCIe card
PCIe NIC$ Temp
PCIe card chip
temperature
PCIe card
PCIe FC$ Temp
PCIe card chip
temperature
PCIe card
RAID Card BBU
RAID controller card BBU
BBU supercapacitor of
LSI SAS3106 RAID
controller card
SM380 Temp
25GENIC chip
temperature
PCIe card
PCIe$ NIC Temp
PCIe card chip
temperature
PCIe card
PS$ Inlet Temp
PSU air inlet temperature
PSU
NIC$ Presence
LOM presence
FlexIO
CPUN AEP Temp
CPU DCPMM
temperature
DCPMMs of CPUN
N indicates the CPU
number. The value is 1 or
2.
FPGA# Temp
FPGA card temperature
PCIe card
