Indicator and Button Descriptions
Table 5-1 Description of indicators and buttons on the front panel
⚫
---: The device is operating properly.
⚫
Error code: A component is faulty.
For details about error codes, see the
FusionServer Rack Server iBMC Alarm
Handling.
Power indicator:
⚫
Off: The device is not powered on.
⚫
Steady green: The device is powered on.
⚫
Blinking yellow: The iBMC is starting. The
power button is locked and cannot be
pressed. The iBMC is started in about 1
minute, and then the power indicator is steady
yellow.
⚫
Steady yellow: The device is standby.
Power button:
⚫
When the device is powered on, you can
press this button to gracefully shut down the
OS.
NOTE
For different OSs, you may need to shut down the OS
as prompted.
⚫
When the device is powered on, holding down
this button for 6 seconds will forcibly power off
the device.
⚫
When the power indicator is steady yellow,
you can press this button to power on the
device.
The UID button/indicator helps identify and
locate a device.
UID indicator:
⚫
Off: The device is not being located.
⚫
Blinking or steady blue: The device is being
located.
UID button description:
⚫
You can control the UID indicator status by
pressing the UID button or using the iBMC.
⚫
You can press this button to turn on or off the
UID indicator.
⚫
You can press and hold down this button for 4
to 6 seconds to reset the iBMC.
