FUTABA T16IZ User Manual

12
→ GO to TABLE OF CONTENTS
Features
FASSTestsystem
The T16IZ transmitter has adopted the bidirectional communication system "FASSTest". Data from the receiver can be checked in
your transmitter. FASSTest is a maximum 18 channels 2.4 GHz dedicated system.
ColortouchscreenLCD
T16IZ has an HVGA 4.3 inch, full-color, backlit LCD touch screen. The screen is transflective which enables both indoor and
outdoor visibility.
S.BUS2system
By using the S.BUS2 system multiple servos, gyros and telemetry sensors are easily installed with a minimum amount of cables.
Modeltypes
Multicopter. 8 swash types are available for helicopters. 7 wing types and 3 tail types are available for airplanes and gliders.
Functions and mixing functions necessary for each model type are set in advance at the factory.
Lithium-ionpolymerbattery
T16IZ is operated by a 7.4 V/2,000 mAh Lithium-ion polymer battery.
microSDcard(SecureDigitalmemorycard)(Notincluded)
Model data can be saved to a microSD card (SD:32MB-2GB SDHC:4GB-32GB). When T16IZ transmitter software files are
released, the software can be updated by using a microSD card update.
Editbutton
Two edit buttons are provided, and the operating screen can be immediately “Returned” to the HOME screen during operation.
Setting operation can be performed easily by combining this button with a touch sensor.
Vibrationfunction
Selects a function that alerts the operator to various alarms by vibrating the transmitter in addition to sounding a buzzer.
Speech function
A function is equipped which allows the system to provide telemetry data audibly. This function can also be utilized with
commercially available earphones.
Contents and Technical Specications
(Specications and ratings are subject to change without notice.)
•T16IZTransmitter
•R7108SBReceiver
•LT2F2000BLiPoBattery
Transmitter T16IZ
(2-stick,18-channel,FASSTest-2.4GHzsystem)
Transmittingfrequency:2.4GHzband
System:FASSTest18CH/FASSTest12CH/S-FHSS/T-FHSS/
FASSTMULT(Europeisnotsupported)/FASST7CH(Europeisnotsupported)switchable
Powersupply:7.4 VLT2F2000BLiPobattery
Frequencyband:2.4GHz
RFpoweroutput:100mWEIRP
Receiver R7108SB
(FASSTest-2.4GHzsystem,DualAntennaDiversity,S.BUS/S.BUS2system)
Powerrequirement:3.7V-7.4VbatteryorregulatedoutputfromESC,etc.(*1)
Size:0.98x1.86x0.56in.(24.9x47.3x14.3mm)
Weight:0.42oz.(12.0g)
Frequencyband:2.4GHz
RFpoweroutput:25mWEIRP
(*1) When using ESCs make sure that the regulated output capacity meets your usage application.
Note:Thissetdoesnotincludeacharger.UseacommerciallyavailableUSBchargerAC
adapter(USB-Atype5V-2A)ortheFutabaoptionalUSBACadapter.
Note:ThebatteryintheT16IZtransmitterdoes notarrivealreadyattachedtothebattery
connector.Pleaseconnectthebatteryconnectorbeforeuse.
•USBCable
•HexKey
•TxStrap
• Short Manual
*The contents may vary on the type of set.

FUTABA T16IZ Specifications

General

Channels	16
Frequency	2.4GHz
Telemetry	Yes
Voice Alerts	Yes
SD Card Slot	Yes
USB Port	Yes
Trainer Port	Yes
Modulation	T-FHSS, S-FHSS
Display	4.3-inch color touchscreen
Battery	7.4V 2000mAh
Model Memory	30 models
