FUTABA T16IZ - AileronDifferential

128
→ GO to TABLE OF CONTENTS
AIL 3
(Chip Aileron)
AIL 4
(Chip Aileron)
AIL1
(Main Aileron)
AIL 2
(Main Aileron)
Aileron di󱐯erential
[Airplane/glider, 2 ailerons or more]
The left and right aileron differential can be
adjusted independently. The differential rate can
also be adjusted according to the flying state by
setting a ne tuning VR.
*The display screen is an example. The actual
screen depends on the Model Type.
Setting method
● Tap to the aileron (AIL) 1~4(2) left (or right)
setting item.
Adjust the aileron angles.
● When setting the fine tuning VR, tap the "--"
item and tap the screen to call the selection
screen, and then select the ne tuning VR.
● The ne tuning rate can be set by curve.
● Select [Aileron differential] at the model
menu and call the setup screen shown
below.
Condition group/single
mode selection (Gr. /Sngl)
(For more information, see
the description at the back
of this manual.)
Currently selected condition name
Fine tuning VR setting
*The graph is operated by setting a VR, etc.
Aileron left/right
adjustment
● Fine tuning VR operation curve setting
(For a description of the setting method, see the
description at the back of this manual.)
●Return to Model menu
Aileron differential
Aileron differential
