152
→ GO to TABLE OF CONTENTS
RUDDER 1
Winglet
at Flying wing
( )
RUDDER 2
Winglet
at Flying wing
( )
Winglet
[Corresponding model type]: Airplane/glider, winglet(2RUD)
This function adjusts the left and right rudder
angles of airplanes with winglets.
It can be used for special airplanes with two
rudders. The amount of movement of the two
mounted rudder servos can be adjusted separately.
Two servos are operated with one rudder stick.
(Rudder 1/2)
The travel at rudder stick left and right
operation can be individually set.
● Select [Winglet] at the model menu and
call the setup screen shown below.
● Travel adjustment
Tap to the item you want to adjust.
Adjust the rate using the "▼▼" "▼" "▲" "▲▲"
buttons.
*If the mixing direction is reversed by the linkage,
adjustments can be made by changing the mixing rate
polarity (+ or -).
Condition group/
single mode
selection (Gr. /Sngl)
●Return to Model menu
To Next Page
