Part number ordering example: DMC-4010(ETL)-C012-I000
MO – Motor Off Jumpers Installed
When a jumper is installed on the “MO” pins, the controller will be powered up in the “motor off” state. This
option will cause jumper to be installed at the factory.
Part number ordering example: DMC-4010(MO)-C012-I000
CMB, “-CXXX(Y)” Communication Board Options
The following options are the “Y” configuration options that can be added to the -CXXX part number. Multiple Y-
options can be ordered per board.
5V – Configure Extended I/O for 5V logic
The 5V option for the CMB-41012 configures the 32 configurable extended I/O for 5V logic. The standard
configuration for the extended I/O is 3.3V. For more information see the Extended I/O section in Chapter 3.
Part number ordering example: DMC-4010-C012(5V)-I000
RS-422 – Serial Port Serial Communication
The default serial configuration for the DMC-40x0 is to have RS-232 communication on both the Main (P1) and Aux
(P2) serial ports. The controller can be ordered to have RS-422 on the Main, Aux or both serial ports for either the
CMB-41012 (-C012) or the CMB-41022 (-C022). For more information about RS-232 and RS-422 port settings, see
the Serial Communication Ports section in Chapter 4.
Part number ordering example: DMC-4010-C012(P1422)-I000
RS-422-Main Port
Standard connector and cable when DMC-40x0 is ordered with RS-422 Option.
Pin # Signal
1 RTS-
2 TXD-
3 RXD-
4 CTS-
5 GND
6 RTS+
7 TXD+
8 RXD+
9 CTS+
RS-422-Auxiliary Port
Standard connector and cable when DMC-40x0 is ordered with RS-422 Option.
Pin # Signal
1 CTS-
2 RXD-
3 TXD-
4 RTS-
5 GND
6 CTS+
7 RXD+
8 TXD+
9 RTS+
Appendices ▫ 187 DMC-40x0 User Manual
