The message command normally sends a carriage return and line feed following the statement. The carriage
return and the line feed may be suppressed by sending {N} at the end of the statement. This is useful when a text
string needs to surround a numeric value.
Example:
#A
JG 50000;BGA;ASA
MG "The Speed is", _TVA {F5.0} {N}
MG "counts/sec"
EN
When #A is executed, the above example will appear on the screen as:
The Speed is 50000 counts/sec
Using the MG Command to Configure Terminals
The MG command can be used to configure a terminal. Any ASCII character can be sent by using the format {^n}
where n is any integer between 1 and 255.
Example:
MG {^07} {^255}
sends the ASCII characters represented by 7 and 255 to the bus.
Summary of Message Functions
function description
" "
Surrounds text string
{Fn.m}
Formats numeric values in decimal n digits to the left of the decimal point and m
digits to the right
{P1}, {P2} or {E}
Send message to Main Serial Port, Auxiliary Serial Port or Ethernet Port
{$n.m}
Formats numeric values in hexadecimal
{^n}
Sends ASCII character specified by integer n
{N}
Suppresses carriage return/line feed
{Sn}
Sends the first n characters of a string variable, where n is 1 thru 6.
Displaying Variables and Arrays
Variables and arrays may be sent to the screen using the format, variable= or array[x]=. For example, v1= returns
the value of v1.
Example - Printing a Variable and an Array element
Instruction Interpretation
#DISPLAY
Label
DM posA[7]
Define Array posA with 7 entries
PR 1000
Position Command
BGX
Begin
AMX
After Motion
v1=_TPA
Assign Variable v1
posA[1]=_TPA
Assign the first entry
v1=
Print v1
Interrogation Commands
The DMC-41x3 has a set of commands that directly interrogate the controller. When these command are entered,
the requested data is returned in decimal format on the next line followed by a carriage return and line feed. The
Chapter 7 Application Programming ▫ 132 DMC-41x3 User Manual
