Ordering Options
Overview
The DMC-41x3 can be ordered in many different configurations and with different options. This section provides
information regarding the different options available on the DMC-41x3 motion controller, axis-specific options,
and internal amplifiers. For information on pricing and how to order your controller with these options, see our
DMC-41x3 part number generator on our website.
http://galil.com/order/part-number-generator/dmc-41x3
DMC and Form Factor , “DMC-41x3-XXXX(Y)” Options
The following options are the “-XXXX” form factor options that determine how the DMC-41x3 product will be
delivered. See TABLE for example images.
CARD
This is the default option if none is specified and no internal amplifier is being used. If an internal amplifier is being
used, the BOXn (where n stands for 4 or 8) option is required.
Part number ordering example: DMC-4153-CARD
BOX4, BOX8
The BOX4 or BOX8 option on the DMC-41x3 provides a metal enclosure for the controller. BOX4 is the box for the
1-4 axis controllers, the BOX8 is for 5-8 axis controllers. The BOXn option is required when using Galil internal
amplifiers and is recommended for any application that requires CE certification.
Part number ordering example: DMC-4113-BOX4
The following options are the “Y” configuration options that can be added to the DMC part number. Often,
multiple Y-options can be ordered per board as long as they're separated by a comma:
DIN – DIN Rail Mounting
The DIN option on the DMC-41x3 motion controller provides DIN rail mounts on the base of the controller. This
will allow the controller to be mounted to any standard DIN rail. Requires BOX4 or BOX8 option.
Part number ordering example: DMC-4113-BOX4-DIN
12V – Power Controller with 12VDC
The 12V option allows the controller to be powered with a regulated 12V supply. The tolerance of the 12V input
must be within ±5%. If ordered with an internal amplifier, the 12V will automatically be upgraded to the ISCNTL
option, see ISCNTL – Isolate Controller Power, pg 168. The controller will be powered through the 2-pin Molex
connector on the front face of the controller. Molex connector part numbers and power connector pin-outs can be
found here: Power Connector Part Numbers, pg 172.
Part number ordering example: DMC-4113-CARD(12V)
-16 bit – 16 bit Analog Inputs
The -16 bit option provides 16 bit analog inputs on the DMC-41x3 motion controller. The standard resolution of
the analog inputs is 12 bits.
Part number ordering example: DMC-4113-CARD(-16bit)
Appendices ▫ 167 DMC-41x3 User Manual
