GAT SMART.Lock 7000 System
Technical Data
www.gantner.com HB_GAT-SMARTLOCK7000--EN_10 51
7. TECHNICAL DATA
7.1 GAT SMART.Lock 7001
Nominal voltage U
DC
: 24 V
Permitted input voltage U
DC
: 19.2 to 28.8 V (±20%)
Current consumption of the coil: 1 A @ 24 V (500 ms)
Perm. switching current (contact): 1 mA
Std. switching current (contact): Max. 0.1 A
Locking/unlocking cycles: 50,000
Retaining force: Min. 2,000 N
Force on inner side of the door: Max. 50 N
Housing material: Die cast zinc
Housing colour: Grey
Door shackle: MIM 316L
Door width: Min. 230 mm
Installation position: Arbitrary
Connection technique: Socket (MOLEX, type Micro-Fit 3.0™, No. 043020-0401)
Dimensions: 84 x 72 x 18.5 mm (L x W x H)
Permitted ambient temperature: -30 to +60 °C
Storage temperature: -30 to +70 °C
Protective type: IP 52
Protective class: III
Weight: Approx. 0.2 kg
Environmental class based on VDS 2110: II (conditions in indoor areas)
7.2 GAT NET.Controller M 7000
Nominal voltage U
DC
: 24 V
Power supply unit: External power supply unit with different power cables available
Average power consumption: -
Number of GAT SMART.Controller S 7000
per RS 485 line: Max. 8
Memory: Internal memory for 10,000 bookings. SD card slot for memory ex-
pansion, log files, firmware update or person lists
Digital inputs: 4 x optocoupler
Digital outputs: 4 x relay
Communication interface to slave controller: RS 485
Communication interface to server: Ethernet
Connection types: - Master to server (Ethernet): RJ 45 98a
