LMM for the Kodiak 100 Page 4-19
190-02102-00 Rev.4
NAV 2 INOP - CONFIG A NAV software or configuration
fault.
• GIA 64W
NAV 2 INOP - INTRL A NAV internal fault. • GIA 64W
NAV 2 INOP - SERL A NAV serial communication fault. • GIA 64W
NAV 2 INOP - SYNTH NAV synthesizer lock fault. • GIA 64W
NAV2 MANIFEST NAV2 software mismatch. • GIA 64W
NAV2 RMT XFR The NAV2 remote transfer key line
is stuck in the enabled state.
• GIA 64W
NAV2 SERVICE A fault has been detected in the
NAV subsystem of GIA2.
• GIA 64W
PFD1 BACKLIGHT CAL PFD1 backlight calibration lost. • GDU 1050
PFD1 CONFIG PFD1 configuration error. • GDU 1050
• Master Config
Module
PFD1 COOLING PFD1 has poor cooling. Reducing
power usage.
• GDU 1050
PFD1 KEYSTK A key is stuck on the PFD1 bezel. • GDU 1050
PFD1 MANIFEST PFD1 software mismatch. • GDU 1050
PFD1 SERVICE A fault has been detected in
PFD1.
• GDU 1050
PFD1 VOLTAGE PFD1 has low voltage. • GDU 1050
XPDR1 FAIL XPDR1 is inoperative. • GTX 345R
XPDR1 SERVICE A fault has been detected in
XPDR1.
• GTX 345R
XTALK ERROR A flight display crosstalk error has
occurred. A PFD and an MFD are
not communicating with each
other.
• GDU1050
Table 4-1. Troubleshooting System Messages (Continued)
System Message Description
Possibly Faulty
LRU / Subsystem
Uncontrolled if Printed

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
