Garmin G1000 Line Maintenance Manual

______________________________________________________________________________
____________________________________________________________________________
Page 3-28 LMM for the Kodiak 100
190-02102-00 Rev.4
3.11 Aviation Database Loading
1. With the system OFF, remove an SD Card from the top SD card slot of the MFD.
2. Download and install the databases on an SD card.
3. Put the SD Card in the top SD card slot of the MFD.
4. Turn the system ON.
5. Press the ENT Key or the right-most softkey on MFD display to acknowledge the
startup screen.
6. Turn the large FMS Knob and select Aux.
7. Turn the small FMS Knob and select Databases.
8. Monitor the Sync Status on the ‘Aux-Databases’ Page. Wait for all databases to
complete syncing, indicated by ‘Sync Complete’ being displayed. A cyan double
arrow will appear between the Standby and Active columns to show which
Standby databases will be transferred to Active at the next power cycle.
Figure 3-23. Aux - Databases’ Page before Activation of Standby Databases
9. Make sure the correct database cycle information is shown in the Standby col-
umn.
Uncontrolled if Printed

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
