Page 4-30 LMM for the Kodiak 100
190-02102-00 Rev.4
SVT is intended to be used with traditional attitude, heading, obstacle, terrain, and traffic
inputs. SVT is disabled when valid attitude or heading data is not available for the
display. In case of invalid SVT data, the PFD display reverts to the standard blue-over-
brown attitude display.
Since SVT becomes disabled without the following data resources all the following
become candidates for troubleshooting:
• Attitude data
• Heading data
• GPS position data
• 4.9 Arc-second Terrain data
• Obstacle data
• TAWS function is not available, in test mode, or failed
• The position of the aircraft exceeds the range of the terrain database
4.7.1.3.1 SVT System Messages
Table 4-3. SVT System Messages
System Message Cause Recommended Actions
SVT - SVT DISABLED:
Out of available terrain
region
SVT is disabled because
the aircraft exceeded the
boundaries of the loaded
terrain database.
• Ensure that operations are
within the required
geographic area.
SVT - SVT DISABLED:
Terrain DB resolution too
low
The Copilot push-to-talk
(PTT) switch is stuck in
the enabled state.
• Ensure the correct terrain
cards are installed in the
lower slot of each display.
• If terrain data has been
recently updated, ensure
the correct 4.9 arc-second
databases were used.
