Page 4-66 LMM for the Kodiak 100
190-02102-00 Rev.4
TCAS Equipage Fault Broken wire, improper
configuration.
• Verify configuration settings
on the transponder and the
GTS. Ensure proper wiring
between the transponder
and the GTS.
Radio Altitude Fault • Radio Altimeter is not
powered on or
improper wiring.
• Improper configuration
settings.
• Verify the radio altimeter
has power and is properly
wired.
• Verify the configuration is
set correctly using the GTS
Install Tool.
Red 'X' on a data port on
the configuration page
• Improper wiring; wrong
port or speed selected.
• Ensure the port is properly
wired to the GTS and the
correct settings are
selected on the
configuration page.
Table 4-8. GTS Troubleshooting (Continued)
Problem Cause Solution
Uncontrolled if Printed

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
