Garmin G1000 Line Maintenance Manual

______________________________________________________________________________
____________________________________________________________________________
LMM for the Kodiak 100 Page 5-17
190-02102-00 Rev.4
2. To Reinstall:
a) Inspect the connector for damaged pins (3).
b) Place the configuration module (1) in position and insert the connector.
c) Insert the connector into the configuration module (1).
d) Assembly of the connector is the reverse of disassembly.
3. Post-Installation Instructions:
a) If the GRS 79 AHRS Configuration Module is replaced, all three GRS.GMU
calibration procedures must be performed. Refer to Section 7.6.
b) If the GDC 72 Configuration Module is replaced, configuration settings must
be reloaded to the GDC 72. Refer to Section 7.7.
c) If the Master Configuration Module is replaced:
i) Start the G1000 NXi system in configuration mode.
ii) Go to the Configuration Upload Page on the PFD.
iii) Press the UPDT CFG softkey.
4. If both the PFD and the Master Configuration Module are replaced, configuration
must be reloaded to all LRUs in the G1000 NXi system except the GRS 79, GMU
44B, and GDC 72. Refer to Section 3.
Uncontrolled if Printed

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
