Page 7-34 LMM for the Kodiak 100
190-02102-00 Rev.4
9. Connect the directional antenna to the ramp test set.
10. Set the multifunction test set to perform TCAS testing. Press the TAS OPER
softkey on the MFD.
11. Program a static intruder per the following scenario:
Refer to the ramp test set operators manual to set the following
parameters:
• Intruder Start Distance-2 NM Intruder Start Altitude-50,000.
• Vertical Speed-0 fpm Velocity-0 Kts.
12. Set the intruder type as ATCRBS.
13. Ensure a target is annunciated on the MFD at the correct bearing of
approximately 0 degree azimuth at 2 NM and co-altitude (read as 00 above a
filled diamond indicating proximate traffic).
14. Toggle intruder traffic to standby or off.
15. Reposition ramp test set and directional antenna to a starboard position of 90
degrees.
16. Reengage the same intruder scenario as above.
17. Verify a target is annunciated at the correct bearing of approximately 90 degree
azimuth at 2 NM and co latitude.
18. Toggle intruder traffic to standby or off.
19. Reposition ramp test set and directional antenna to an aft position of 180
degrees.
20. Reengage the same intruder scenario as above.
21. Verify a target is annunciated on the MFD at the correct bearing of approximately
180 degree azimuth at 2 NM and co-altitude.
22. Toggle intruder traffic to standby or off.
23. Reposition ramp test set and directional antenna to a port position of 270
degrees.
24. Reengage the same intruder scenario as above.
25. Verify a target is annunciated on the MFD at the correct bearing of approximately
270 degree azimuth at 2 NM and co-altitude.
26. Toggle intruder traffic to standby or off.
