If Single (1x1), Dual (2x1) or Quad (2x2)
display is selected, the (Setup) button
allows you to select the layout of the
channels to be displayed on-screen.
The drop-down lists are shown on-
screen according to the grid layout
mode selected. You can easily choose
each individual camera channel to be
displayed in the selected grid segment
visually. If you have less cameras than
available grid segments, then those
segments associated with an actual
camera will be displayed as a black box.
Alarm Image Upload – checkbox, if
selected will enable the device to
upload the alarm to the centre server.
PB Alarm Duration – numeric text
field to set the duration of the video
playback (in seconds) when the alarm
occurs.
Alarm Snap – checkbox – if selected,
when the alarm occurs, the device will
take snapshots using the selected
cameras.
DEFAULT SETTINGS:
Disabled/not applicable.
Checkbox – if selected, enables the device to
monitor for Driver Alert Button presses. In case
of the panic button on the panel being pressed,
this alarm will be triggered.
DEFAULT SETTINGS:
Checkbox – Selected
