Enable
Checkbox – if selected, will enable the device to
monitor the associated IO input line for an
alarm trigger.
DEFAULT SETTINGS:
BRAKE – Checkbox – Selected
WARNING – Checkbox – Selected
STOPARM – Checkbox – Selected
DOOR – Checkbox – Selected
LEFTTURN – Checkbox – Selected
RIGHTTRN – Checkbox – Selected
EXTRA1 – Checkbox – Unselected
EXTRA2 – Checkbox – Unselected
Alarm Type
Drop-down list to select the classification level
for the alarm:
Event
Alarm
DEFAULT SETTINGS:
For all IO lines, set to:
Alarm
Trigger
Click the (Setup) button under Trigger to
display the Trigger setup screen for the
associated IO input line.
This will display a drop-down list which allows
you to select the trigger for this IO input line:
Low (0V)
High (12V – 24V)
DEFAULT SETTINGS:
By default, all the IO line triggers will be set to
High. However, please adjust any or all of these
values as appropriate, as whether the trigger
value is High or Low will depend on the vehicle
and the wiring.
Linkage
Click the (Setup) button under Linkage to go
to the Linkage setup screen. This sets up the
video display, recording and snapshot options
associated with this alarm.
The Linkage setup screen enables you to
configure the following options:
