Linkage Screen – drop-down list to
select the options to display the video
from the selected cameras on-screen
when the alarm occurs.
None
: Not displayed
Single
: Display 1 camera.
Dual
: Display 2 cameras.
Quad
: Display 4 cameras.
If Single (1x1), Dual (2x1), or Quad (2x2)
display is selected, the (Setup) button
allows you to select the layout of the
channels to be displayed on-screen.
The drop-down lists are shown on-
screen according to the grid layout
mode selected. You can easily choose
each individual camera channel to be
displayed in the selected grid segment
visually. If you have less cameras than
available grid segments, then those
segments associated with an actual
camera will be displayed as a black box.
PB Alarm Duration – numeric text
field to set the duration of the video
playback (in seconds) when the alarm
occurs.
Alarm Snap – checkbox – if selected,
when the alarm occurs, the device will
take snap shots using the selected
cameras.
DEFAULT SETTINGS:
Please choose the camera channels to display
and record in the event of this alarm being
triggered. These settings would need to be
determined by the customer/client to match
their specific business requirements.
IO Alarm
Name
The list of available IO inputs triggers is listed
on the screen. You may use the (˄) and (˅)
buttons to scroll the list.
