Channel – checkboxes that allow you to select any
combination of the camera channels to be included
in the display and recording.
Post Recording – numeric value box which allows
you to enter the duration for which video will
continue to be recorded when the alarm is
triggered.
Lock – checkbox, if selected will mark the recorded
video associated with this alarm as a locked video.
Linkage IO Output – checkboxes, if enabled, the
device will send a signal to the selected IO output
lines.
Output Delay Time – numeric text field to set the
delay time for the IO output (in seconds).
Linkage Screen – drop-down list to select the
options to display the video from the selected
cameras on-screen when the alarm occurs.
If Single (1x1), Dual (2x1) or Quad (2x2) display is
selected, the (Setup) button allows you to select the
layout of the channels to be displayed on-screen.
The drop-down lists are shown on-screen according
to the grid layout mode selected. You can easily
choose each individual camera channel to be
displayed in the selected grid segment visually. If
you have less cameras than available grid segments,
then those segments associated with an actual
camera will be displayed as a black box.
Alarm Image Upload – checkbox, if selected will
enable the device to upload the alarm to the centre
server.
PB Alarm Duration – numeric text field to set the
duration of the video playback (in seconds) when
the alarm occurs.
Alarm Snap – checkbox – if selected, when the
alarm occurs, the device will take snapshots using
the selected cameras.
DEFAULT SETTINGS:
Disabled/not applicable.
